STANDARDS




                    Despite a revision of EN ISO 20345 in 2022, EN ISO 20345:2011 is still valid  for new certification until November 11, 2024.
                           Therefore, all certificates issued up to this date will be valid for 5 years, i.e. until November 11, 2029.
                                    During this transition period, the two versions of the standards will coexist.
                       In our next 2024 catalog, we'll be unveiling all aspects of these new standards requirements, the new CE markings
                                markings and their impact on the technological and safety choices of our collections.



                            FUNDAMENTAL   ADDITIONAL
             CATEGORIES                                     SYMBOLS                           REQUIRED MINIMUM VALUES
                            REQUIREMENTS  REQUIREMENTS              ADDITIONAL SYMBOLS USED   EN ISO 20345:2011 +
                                                                                              EN ISO 20347:2012
           EN ISO
          20345:2011  EN ISO  Class I  Class II
         Toe 200 J/15kN  20347:2012  (shoe)  (boot)                 Resistance to perforation  P   ≥ 1100 Newton
                             •     •                                  Electric resistance:              5    9
            SB                                                      - Antistatic           A    between 1x10  Ω a 1x10  Ω
                                                                                                         5
                                                                    - Conductive           C         < 1x10  Ω
                             •         Closed heel area       A     Resistant to harsh environments :
                                       Antistatic properties
            S1                         Energy absorption in the heel   E  - Cold isolation   CI  by temperature < 10°C
                                                                    - Heat isolation
                             •         Resistance of the sole                              HI    by temperature > 22°C
                     01                                       FO
                                       to hydrocarbons
                                                                    Resistance of the sole against contact   HRO  contact at 300°C for 60 secs –
                                                                                                     no melting
                                                                    heat
            S2       02      •         Same as S1/01 plus:   E/FO                                 always present by
                                       resistance to water penetration
                                                             WRU
                                                                                                  EN ISO 20345:2011
                                                                    Resistance of the sole   FO  and by EN ISO 20346:2011
                                                                    Against hydrocarbons      but to be specified when required
            S3       03      •         same as S2/02 plus:   A/E/WRU/  Energy absorption capacity   by EN ISO 20347:2012
                                       resistance to perforation.
                                                             FO/P
                                       Cleated soles                in the heel area       E         ≥ 20 Joule
                                                                                                no penetration within first
                                                                    Resistance of the whole shoe to water   15 mins.
       Slip resistance of the sole                                  penetration           WR      After 100 flex should
       Regulation: EN ISO 20345:2011 / 20347:2012                                                not penetrate more than
                                                                                                    3 square Cm
                                                                    Resistance of the upper to water
        Marking symbol               Required conditions provided by the regulation  penetration  WRU  > 60 mins - Absorbance < 30%
                                                                    Ankle protection       AN    average value > 20kN
        SRA
        Test surface: ceramics       ≥ 0.32 flat footwear           Shoe with metatarsal protection  M  height after shock > 40 mm (tg 42)
        Lubricant: water and detergeant  ≥ 0.28 footwear inclinated 7° towards the heel
                                                                    Cut resistant upper    CR       l factor > 2,5
        SRB
        Test surface: stainless steel  ≥ 0.18 flat footwear         Features               NO    Stud height >=2,5 cm
        lubricant: Glycerin          ≥ 0.13 footwear inclinated 7° towards the heel  spiked soles   SYMBOL
        SRC                          Both above described conditions required
       Personal Safety Equipments (P.P.E.) are ruled by two   • select the P.P.E. suitable and appropriate to the risks, in   Basing on the analyses and the executed tests for this
       European regulations:                 consultation with the R.S.P.P.     type in conformity to the regulation EN ISO 20344:2011,
                                            • select the P.P.E. compatible with the types of work to   on the technical  documentation  and the  informative
       • the 89/686 CE which defines the obligations of the   be executed and with the principles of ergonomics  notre of use, a CE attestation is released, valid in whole
         producer                           • make the P.P .E. available to the workers  Europe.
       • the 89/656 CE relating to the use, which defines the   • monitor actual usage
         obligations of the companies and the workers.  • provide the P.P.E. for free and for personal use
                                            • ensure the proper functioning, the hygienic status and   Notes
       Safety, protectional and professional footwear are   maintenance         It is forbidden to affix on a P.P.E., on it's box and on any
       identified as Personal Safety Equipments  • proceed or o carry out periodical general checks for   other pertinent document any brand or writing susceptible
                                             some categories of P.P.E.          to create confusion with the markings provided within the
                                            • ensure information, education, instruction, training of   framework of the certification procedures in conformity
       OBLIGATIONS OF THE PRODUCER           the use of P .P.E. And the risks covered  with Art. R233.50.1
       By purchasing Jallatte  products you are assured that all   • prepare a delivery note of the P.P.E. For the worker
                     ®
       footwear have met the certification procedures based on
       the European regulations, as shown by the CE marking.   And further:
       Each box contains an informative note of use which   • the P.P.E. are not to be considered prizes in kind
       establishes the risks covered. For every model, Jallatte    • the responsability of the worker is only  disciplinary
                                         ®
       issues a declaration of conformity.   (omission to wear the protections) and is subordinated
                                             to a criminal matter responsability of the employer
       OBLIGATIONS OF THE COMPANIES AND THE   THE CERTIFICATION PROCEDURES
       WORKERS                              All Jallatte  footwear belongs to class II (protection
                                                  ®
       besides the priority of collective protection, the directive   against severe risks). Therefore all footwear is submitted
       establishes an obligation of health and safety. The   to the specific CE examination at an enabled blody at a
       employers must:                      European level’.
       • locate the risks which cannot be avoided through
         collective protection
       This catalogue replaces all previous documents.
       With the aim to improve our collections, all products included in this catalogue may be replaced and/or modified.
       Images are for illustration purposes only and are not legally binding.
